Home » Led Linear vapor light Explosion-Proof Fixture2FT-30W-4200Lumens
Uslighting

Led Linear vapor light Explosion-Proof Fixture2FT-30W-4200Lumens

In stock
$243.00
130LM/W /Average Life>150,000H
5 Years Warrenty
UL1598/UL1598A/UL844 Certified
IP66/IK10&-40°C to +40°C (T6)
Color

if u need to buy in bulk, contact us

Features


● UV stabilized, impact-resistant fiberglass reinforced polycarbonate lens
● Available in two and four foot lengths
● Safety interlock kit design
● Light distribution 120 degree
● 0-10V dimming
● Replaceable LED light strip
● Water-proof, vapor-proof, dust-proof, and corrosion resistant
● Optional emergency battery back-up (self-contained min. 180 minute with Push-to-test button and LED charging
indicators)


Compliance


UL 844 Hazardous Locations
Class I Division 2, Group A, B, C, D

ABS
IP66 (wet location)
IK10


Application


● Power Plants
● Heavy Industrials Storage Facility
● Paper mills
● Wastewater Treatment Plants
● Loading Docks Platforms
● Offshore Environments
● Chemical Processing Facility
● Petrochemical Processing Facility
● Metallurgical Industry
● Coal Mine
● Food and Alcohol industry
Wattage(s) 30W
Luminous Efficacy (lm/W) 130 lm/W
Average Lamp Life >150,000 hours
Color Temperature(s)
5000K
CRI ＞70
Dimming 0-10V
Base Type Fixture
Beam Angle 120°
Working Environment Harsh and hazardous locations
Protection IP66/IK10/3G vibration/1200 hours salt spray
Light Type HazLoc
Input Voltage 120~277VAC
Temperature Rating -40°C to +40°C (T6)
Housing Material  FRP (Fiber Reinforced Plastics)
Housing Color Milky white
Qty in Package 1
Dimensions 31.5'‘x9.8’'x6.7'‘
Weight 11.02lbs
Certification ETL,DLC
Warranty 5-Year Standard Warranty

Clip here to download a detailed PDF about the product
